URay 8 in 1 H.265 H.264 HDMI To IP Video Encoder 8 Channels Live Streaming Encoder HD Encoders H265

• Support H.265/HEVC, H.264 /AVC, MJPEG video encoding

  Support AAC, AAC+, AAC++,MP3, MP2, AC3, Opus, G.711 audio encoding

• Support to live streaming on 2 live broadcast platforms simultaneously for each channel

  2 streams output for each channel, support different protocol transmission for each stream

• Support output video frame rate setting, max 60fps input and output

  Support output video resolution setting, max 1920x1080P input and output

• Choose suitable streaming URL to prioritize bandwidth consumption or image quailty

  Support SRT, HTTP, RTSP, RTMP(S), HLS(M3U8), UDP, RTP, FLV, ONVIF, Unitcast etc protocol

• Support on screen display settings, such as logo /text /scroll text /time etc

  Support customize the no signal image when there is no input signal

• Provide SDK /API /CGI for secondary development

  Support logo printing /language /firmware /function etc customization

• Set up for the first time, plug and play when use it later

  Not only RTMP(S), but also streaming HLS to YouTube or other server(New feature)







Model No.	UHE265-8
Video
Input Video	8xHDMI, Support HDCP
Input Resolution	Max 1920x1080 resolution, max 60fps frame rate
Video Encoding	H.265 /H.264 AVC, MJPEG
Encoding Levels	H.265 main, H.264 high /main /baseline profile
Video Bitrate	Adjustable From 32kbit /s to 32mbit /s
Bitrate Control	CBR, VBR, Strong CBR
Output Resolution	It is adjustable, max 1920x1080P /60fps
Video Pre-processing	De-interlacing, noise reducing, sharpening etc
Audio
Input Audio	HDMI embedded audio
Output Audio	HDMI embedded audio
Sampling Rate	44.1KHz, 48KHz, Same as the input
Bitrate Control	Adjustable from 48000~320000
Audio Encoding	AAC, AAC+, AAC++, MP3, MP2, AC3, Opus, G.711
Network
Interface	Ethernet port(1000 BASE-T)
Streaming Protocol	HTTP, SRT, RTSP, RTMP(S), HLS, O NVIF, UDP, RTP, Unitcast etc
Control Panel	Webpage UI(language customizable)
Firmware Update	Enable by uploading firmware to dashboard and upgrade
General
Dimension (W* L* H)	230 x 105 x 44 /mm
Net Weight	500g
Temperature	0 to 45(For working), -20 to 80(For storing)
Input Voltage	DC 12V /2A
Material	Aluminum Shell

• Status Display



• Stream Setting



• OSD Setting



• Upgrade
