Dimensional Video Networks

3D Scanner SHINNING High-precision 3D Scanning 2x plus HD

Name: 3D Scanner SHINNING High-precision 3D Scanning 2x plus HD
Brand: Dimensional Video Networks
SKU: 192432594013900_478146836
Price: 7689.36 USD
Availability: InStock

$7,689.36 USD

~~$0.00 USD~~ $7,689.36 USD

Sale Sold out

Model Number EINSTAR 2x HD

Product variants

Quantity

Specification

Model	3D Scanner Pro 2X 2020 (EinScan Pro 2X 2020)
Scan Mode	Handheld HD Scan	Handheld Rapid Scan	Fixed scan with turntable (with Add-onIndustrial Pack)	Fixed scan without turntable (with Add-on Industrial Pack)
Scan Accuracy	up to 0.05 mm	up to 0.1 mm	0.04 mm‪ (single shot accuracy)	0.04 mm (singel shot accuracy)
Scan Speed	20 fps;100,000 points/s;7 data capture lines	30 fps;1,500,000 points/s	Single Scan: < 1 s	Single Scan: < 1 s
Volumetric Accuracy*	0.3 mm/m (Markers Alignment)	0.3 mm/m (Markers Alignment)	/	/
Point Distance	0.2 mm-2 mm	0.2-2 mm	0.16 mm	0.16 mm
Texture Scan	No	Yes (with Add-on: Color Pack)	Yes (with Add-on: Color Pack)	Yes (with Add-on: Color Pack)
Single Scan Range	135100 mm--225170 mm
Depth of Field	±100 mm
Working Distance	400 mm
Light Source	LED
Outdoor Operation	Set up the shelter or cover to avoid direct sunlight
Special Objects for scanning	For the transparent, highly reflective or some dark objects, please spray powder before scanning
Printable Data Output	Able to export watertight 3D model directly to 3D printing
Output Formats	OBJ , STL , ASC , PLY , P3, 3MF
Scanner Body Weight	1.13kg (include the USB3.0 cable)
Supported OS	Win 7, Win 8, Win 10, 64 bit
Recommended configuration	Graphics card: NVIDIA GTX1060 and higher; video memory: >4G, processor: I7-8700, memory: 32G; interface: high-speed USB 3.0
Required configuration	Graphics card: Quadro card P1000 and above or NVIDIA GTX660 and higher; processor: Intel (R) xeon E3-1230, Intel (R) I5-3470, Intel (R) I7-3770; interface: high-speed USB 3.0; memory: 8G

Show details

Portable & User-friendly Design

With a light weight and compact size, you can easily take the EinScan Pro 2X 2020 anywhere like a laptop, enjoy plug-and-play installa-tion and unlimited scanning experience.

Scan Faster than Ever Before

The latest development in data capture hardware and optimized algorithms, makes EinScan Pro 2X 2020 a dramatic breakthrough in scanning speed, processing up to 1,500,000 points per second (30 fps) under Handheld Rapid Scan Mode.

High Speed Data Transmission - USB 3.0

High Accuracy

Single scan accuracy under Fixed Scan Mode is up to 0.04 mm. When using markers, the volumetric accuracy under handheld scanning modes is up to 0.045mm+0.3mm/m.

Catch Fine Details

The minimum point distance is up to 0.2mm under Handheld
Rapid Scan and Handheld HD Scan modes, generating high resolution 3D data.

Versatile Scan Modes & Align Modes
Supports Handheld Rapid Scan, Handheld HD Scan, Fixed Scan without Turntable, and Fixed Scan with Turntable modes, as well as mul
tiple alignment modes including feature alignment, marker alignment, texture alignment, turntable coded targets alignment, and manual alignment.
Modular Design to Meet Wider Range of Applications
Color Pack and Industrial Pack, as optional add-ons to EinScan Pro 2X 2020 for various scanning experiences and applications.
